Model | 3E1 | 3E2 | 4E1 | 4E2 | 4E2C.P.R |
Bore No. | 15A | ||||
Port size | G 1/2 | ||||
No. of port | 3 | 5 | |||
No. of position | 2 | 3 | |||
Medium | Air | ||||
Operating pressure range | 0.2~0.7 MPa | 0.3~0.7 MPa | |||
Operating pressure(LP) | 0~0.7 MPa | ||||
Extemal pilot pressure(LP) | 0.2~0.7 MPa | 0.3~0.7 MPa | |||
Proof pressure | 1 MPa | ||||
Effective orifice | 50 mm² | 30 mm² | |||
Ambient temperature | -5 ~ +50℃ (No freezing) | ||||
Response time | 50 ms | ||||
Voltage | AC110V, 220V(50/60)Hz, DC24V | ||||
Power consumption | AC=6/4.9VA DC=2.5W | ||||
Avaiable voltage range | ±10% | ||||
Insulation class | F class | ||||
Weight(g) | 353 | 437 | 330 | 452 | 634 |
Weight(Explosion)(g) | - | 570 | 925 | 1106 |
