Model | UACP403 | ||
Bore No. | 8A | 10A | 15A |
Port size | PT(Rc) 1/4 | PT(Rc) 3/8 | PT(Rc) 1/2 |
Medium | Air | ||
Operating pressure range | 0.05~1 MPa | ||
Proof pressure | 1.5 MPa | ||
Regulated pressure range | 0.1~0.85 MPa | ||
Ambient temperature | -5 ~ +60℃ (No freezing) | ||
Filter element | Standard : 40μm Option : 5μm | ||
Lubricating oil capacity | 140cc | ||
Min. flow for oil drip | 30 ℓ/min | 65 ℓ/min | 80 ℓ/min |
Recommended Iubricating oil | Turbine oil ISO-VG32 | ||
Attachment | Pressure gauge(PG-20),T-type bracket | ||
Weight | 1100g |
● Standard unit contains semi-auto-drain function when operating pressure below 0.05MPa。
● Choose auto-drain FMRF300,the pressure range is 0.15~1 MPa。
