Model | UACP200 | |
Bore No. | 6A | 8A |
Port size | PT(Rc) 1/8 | PT(Rc) 1/4 |
Medium | Air | |
Operating pressure range | 0.05~1 MPa | |
Proof pressure | 1.5 MPa | |
Regulated pressure range | 0.05~0.85 MPa | |
Ambient temperature | -5 ~ +60℃ (No freezing) | |
Filter element | Standard : 40μm Option : 5μm | |
Lubricating oil capacity | 20cc, 35cc(UACP200L) | |
Min. flow for oil drip | 35 ℓ/min | 50 ℓ/min |
Recommended Iubricating oil | Turbine oil ISO-VG32 | |
Attachment | Pressure gauge(PG-40),bracket | |
Weight | 432g, 380g(UACP200L) |
● Standard unit contains semi-auto-drain function when operating pressure below 0.05MPa。
