●Suction cup -- sucking
●Tested component -- concealed wire
●Fluid path -- flushing, gluing, stuffing and cooling
●Clamp -- clamping
Specification
| Bore sizes of cylinder (mm) | Ø 25 | Ø 32 | Ø 40 |
| Standard stroke (mm) | 25, 50, 75, 100, 125,150 | ||
| Power fluid | Filtered air with or without lubrication | ||
| Material of cylinder barrel | Stainless steel | ||
| The range of pressure (MPa) | 0.1~1.03 | ||
| The range of temperature (℃) | - 10 ～ + 60 | ||
How to order
 |
