● Piston with magnet is standard accessory.
● Hydro-cylinders of this series can be added with cushions.
Bore sizes of cylinder (mm) | Ø 40 | Ø 50 | Ø 63 | Ø 80 | Ø 100 |
Power fluid | Fitered oil | ||||
Material of cylinder barrel | SUS304 Stainless steel | ||||
The range of pressure (MPa) | 7(70kgf/cm²) | ||||
Proof pressure (MPa) | 10.5(105kgf/cm²) |
||||
The range of speed (mm/sec) | 0.5~300 | ||||
The range of temperature (℃) | -10 ~ +60 |
