● Hydro-pneumatic cylinders are incorporated with converters that make for slow and stable operation and
can be applied for cutting, drilling or middle positioning.
Bore sizes of cylinder (mm) | Ø 32 | Ø 40 | Ø 50 | Ø 63 | Ø 80 | Ø 100 |
Standard Stroke (mm) | Max. 800 | Max. 1200 | Max. 2000 | |||
Power fluid | Filtered air or hydraulic oil | |||||
Material of cylinder barrel | Aluminium alloy | |||||
The range of pressure (MPa) | 0.1 ~ 1.03 | |||||
The range of temperature (℃) | -10 ~ +60 | |||||
The range of speed (mm/sec) | 3 ~ 300 |
